1. The main body adopts national standard channel steel welding, with a multi-layer design, compact structure, small footprint, and greatly improves the space utilization rate of the factory building.
2. The chain is customized with non-standard thickness, 220AX5mm, and pitch 63.5mm.
3. The drying line consists of seven parts: conveyor chain, track, dragging mechanism, tensioning mechanism, lubrication mechanism, support mechanism, and electronic control system.
4. The hanging rod adopts an inner diameter of 25mm axis and an outer diameter of 51mmX3.5mm seamless pipe (or customized), which greatly improves the strength and has no deformation.
5. The two ends of the hanging rod are equipped with imported double bearings to ensure strength and transmission stability.
6. The length of the wire and the number of hanging poles are customized according to the product structure and production capacity of the demand side.
